Wine Cooling
As a temperature-sensitive beverage, the quality and taste of wine are closely related to temperature control during storage and transportation. The drinking temperature of red wine usually ranges between 62-68°F, while white wine’s drinking temperature ranges between 49-55°F.
The challenge lies in designing a cooling system that can fit into the compact space of a wine cooler while providing sufficient cooling capacity.
Traditional cooling systems often occupy too much space, leaving little room for the wine bottles. Additionally, they may not be able to provide the desired level of temperature control, resulting in inconsistent temperatures within the cooler. Nowadays, advanced wine coolers can cool each bottle to an independent temperature. Efficient miniature chiller units can provide precise heat control, low noise, and low vibration operation to ensure that wine is properly stored and served.
MOIR miniature DC refrigeration units are pivotal to the food and beverage industry. The mini DC chiller is assembled with our in-house developed and manufactured small compressor, ensuring a proper safe temperature and maintaining the health and safety regulations. Nowadays, consumers are increasingly seeking convenient ways to cool and store their beverages quickly, whether at home, in offices, in hotels, or at events. Designed with 24V/48V direct current input power, our miniature chiller offers great flexibility and portability, especially in situations of limited poor accessibility to the traditional power supply.
MOIR Compact Plate Cooling Unit
The benefits of Plate liquid chiller module include ultra small radiator and high heat flux. It provides excellent cooling performance and also allows the end user to adapt for ultimate flexibility.
- Refrigerant : R-134a/ R290
- Capacity: 100~600W adjustable
- Rated Voltage: 24V/ 48V DC
- Temperature Range: ±20℃ (-4~68℉)
- Compressor: Twin-motor inverter
- Dimension: 197 x 190 x 148mm
- Weight: 3.6kg (7.92lbs)
The mini cooling unit is a hermetically sealed refrigeration subsystem. It consists of a miniature variable speed dc compressor, condenser, evaporator, and drive board, capillary, and filter drier, fans, and other electrical parts.
The system is compact, lightweight and highly reliable that makes it well-suited for many portable applications. It is fully charged with natural R290 refrigerant and offers high heat transfer rates. The users can easily connect their coolant loop to the evaporator.
A quick glimpse of its feature highlights.
- Compact: Based on our own variable-speed, miniature compressors, we provide the smallest packaged cooling solutions with the highest capacity.
- Powerful: While our thermal units are small, often less than a shoebox, our cooling capacity is not. Powered by our compressor, our compact systems deliver capacity greater than system 10 times their size.
- Efficiency: Moir’s mini chiller, with high efficient, twin-cylinder compressor, has demonstrated higher efficiency than any other compact thermal solution on the market
- Reliable: With years of small or mobile refrigeration technology serving the world for the critical equipment applications, Moir’s mini chiller units have proven durability. Our ISO Quality Management System ensures highly reliable systems and fewer service calls.
The small cooling unit employing variable-speed BLDC inverter compressors is an alternative to widespread thermoelectric coolers for wine cooling. Because the miniaturized compressor-based chiller assembly is compact, robust, and completely self-contained, it allows the end user to adapt to their cooling systems for ultimate flexibility. Plus, the inherent reliability and energy efficiency of such a chiller are attractive to product managers and consumers alike.
Ongoing advancements in cooling technology have led to the development of more efficient and compact chiller modules. MOIR, an innovative miniature cooling supplier, as always, has the ambition to deliver the highest possible efficiency while meeting the latest market requirements and global energy regulations. R290 refrigerant has no direct contribution to global warming and its energy consumption is 30%+ lower than the similar application with R134a or R404. Moir offers the most extended range of high-efficiency Green Cooling solutions for 290 intending to provide quality and environmentally-friendly products.
